- Datasheet BAP50-04W
BAP50-04W,115 Datasheet
Datasheet specifications
| Datasheet's name | BAP50-04W |
|---|---|
| File size | 200.472 KB |
| File type | |
| Number of pages | 9 |
Download Datasheet BAP50-04W |
Download Datasheet |
|---|
Other documentations
No other documentation was found!
Technical specifications
- RoHS: true
- Category: Radio Frequency Chip/Antenna/RF Switches
- Datasheet: NXP Semicon BAP50-04W,115
- Package: SOT-323(SC-70)
- Manufacturer: NXP Semicon
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Diode Type: PIN - 1 Pair Series Connection
- Voltage - Peak Reverse (Max): 50V
- Current - Max: 50mA
- Capacitance @ Vr, F: 0.5pF @ 5V, 1MHz
- Resistance @ If, F: 5Ohm @ 10mA, 100MHz
- Power Dissipation (Max): 240mW
- Operating Temperature: -65°C ~ 150°C (TJ)
- Package / Case: SC-70, SOT-323
- Supplier Device Package: SOT-323-3
- Base Part Number: BAP50
- detail: RF Diode PIN - 1 Pair Series Connection 50V 50mA 240mW SOT-323-3
