DS9503P+T&R Datasheet

DS9503P+T&R

Datasheet specifications

Datasheet's name DS9503P+T&R
File size 96.097 KB
File type pdf
Number of pages 4

Download Datasheet DS9503P+T&R

Download Datasheet

Other documentations

21-0382 Pkg Drawing 1 pages

DS9503 4 pages

Technical specifications

  • RoHS: true
  • Category: TVS/Fuse/Board Level Protection/ESD Protection Devices
  • Datasheet: Analog Devices Inc./Maxim Integrated DS9503P+T&R
  • Number of Lines: 1
  • Clamping Voltage@Ipp: -
  • Operating Temperature: -40°C~+85°C@(Ta)
  • Breakdown Voltage (VBR): -
  • Peak Pulse Power(Ppp)@8/20us: -
  • Junction Capacitance(Cj)@1MHz: -
  • Peak Pulse Current(Ipp)@8/20us: -
  • Reverse Stand-Off Voltage (Vrwm): 7.5V
  • Package: TSOC-6
  • Manufacturer: Analog Devices Inc./Maxim Integrated
  • Applications: General Purpose
  • Capacitance @ Frequency: -
  • Voltage - Reverse Standoff (Typ): 7.5V
  • Voltage - Clamping (Max) @ Ipp: -
  • Current - Peak Pulse (10/1000µs): -
  • Supplier Device Package: 6-TSOC
  • Package / Case: 6-LSOJ (0.148", 3.76mm Width)
  • Power - Peak Pulse: -
  • Part Status: Active
  • Type: Zener
  • Series: -
  • Unidirectional Channels: 1
  • Mounting Type: Surface Mount
  • Voltage - Breakdown (Min): -
  • Power Line Protection: No
  • Packaging: Cut Tape (CT)
  • Base Part Number: DS9503
  • detail: Clamp Ipp Tvs Diode Surface Mount 6-TSOC
