MCP1711T-25I/5X Datasheet

MCP1711

Datasheet specifications

Datasheet's name MCP1711
File size 2029.659 KB
File type pdf
Number of pages 36

Download Datasheet MCP1711

Download Datasheet

Other documentations

No other documentation was found!

Technical specifications

  • Manufacturer: Microchip Technology
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Output Configuration: Positive
  • Output Type: Fixed
  • Number of Regulators: 1
  • Voltage - Input (Max): 6V
  • Voltage - Output (Min/Fixed): 2.5V
  • Voltage - Output (Max): -
  • Voltage Dropout (Max): 0.92V @ 150mA
  • Current - Output: 150mA
  • Current - Quiescent (Iq): 1.27µA
  • Current - Supply (Max): 1.8µA
  • PSRR: -
  • Control Features: Enable
  • Protection Features: -
  • Operating Temperature: -40°C ~ 85°C
  • Mounting Type: Surface Mount
  • Package / Case: 4-UDFN Exposed Pad
  • Supplier Device Package: 4-UQFN (1x1)
  • Base Part Number: MCP1711
  • detail: Linear Voltage Regulator IC 1 Output 150mA 4-UQFN (1x1)
