- دیتاشیت LPC804
LPC804M101JDH24FP دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | LPC804 |
|---|---|
| حجم فایل | 3894.764 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 87 |
دانلود دیتاشیت LPC804 |
دانلود دیتاشیت |
|---|
سایر مستندات
مستندات دیگری یافت نشد!
مشخصات فنی
- RoHS: true
- EEPROM: -
- CPU Core: ARM Cortex-M0
- Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
- RAM Size: 4KB
- Watchdog: -
- ADC (Bit): 12bit
- DAC (Bit): 10bit
- Datasheet: NXP Semicon LPC804M101JDH24FP
- PWM (Bit): -
- Real-Time Clock: -
- CPU Maximum Speed: 15MHz
- GPIO Ports Number: 21
- Low-Voltage Detect: -
- CCP Capture/Compare: -
- Internal Comparator: -
- Internal Oscillator: Yes
- Peripheral/Function: PWM;WDT
- Program Memory Type: FLASH
- Direct Memory Access: -
- Program Storage Size: 32KB
- Universal Serial Bus: -
- communication protocol: -
- Operating Voltage Range: 1.71V~3.6V
- Infrared Data Association: -
- Operating Temperature Range: -40°C~+105°C
- Secure Digital Input and Output: -
- Package: TSSOP-24
- Manufacturer: NXP Semicon
- Series: LPC80xM
- Packaging: Tray
- Part Status: Active
- Core Processor: ARM® Cortex®-M0+
- Core Size: 32-Bit
- Speed: 15MHz
- Connectivity: I²C, SPI, UART/USART
- Peripherals: Brown-out Detect/Reset, POR, PWM, WDT
- Number of I/O: 21
- Program Memory Size: 32KB (32K x 8)
- EEPROM Size: -
- Voltage - Supply (Vcc/Vdd): 1.71V ~ 3.6V
- Data Converters: A/D 12x12b; D/A 1x10b
- Oscillator Type: Internal
- Operating Temperature: -40°C ~ 105°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 24-TSSOP (0.173", 4.40mm Width)
- Supplier Device Package: 24-TSSOP
- Base Part Number: LPC80
- detail: ARM® Cortex®-M0+ LPC80xM Microcontroller IC 32-Bit 15MHz 32KB (32K x 8) FLASH 24-TSSOP
