دیتاشیت MAX14757EUE+T
مشخصات دیتاشیت
| نام دیتاشیت |
MAX14756-58
|
| حجم فایل |
886.207
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
12
|
مشخصات
-
RoHS:
true
-
Category:
Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
-
Datasheet:
Analog Devices Inc./Maxim Integrated MAX14757EUE+T
-
Turn-on time:
60us
-
Turn-off time:
3us
-
Supply Voltage:
10V~70V
-
Switch Circuit:
SPST(SPST)-Normal Open
-
Number of Channels:
4
-
On-State Resistance (Max):
10Ω
-
Package:
TSSOP-16
-
Manufacturer:
Analog Devices Inc./Maxim Integrated
-
Multiplexer/Demultiplexer Circuit:
1:1
-
Part Status:
Active
-
Charge Injection:
580pC
-
-3db Bandwidth:
145MHz
-
Operating Temperature:
-40°C ~ 85°C (TA)
-
Voltage - Supply, Dual (V±):
±10V ~ 35V
-
Supplier Device Package:
16-TSSOP
-
Package / Case:
16-TSSOP (0.173", 4.40mm Width)
-
Switch Time (Ton, Toff) (Max):
60µs, 3µs
-
Packaging:
Cut Tape (CT)
-
Channel-to-Channel Matching (ΔRon):
300mOhm
-
Voltage - Supply, Single (V+):
10V ~ 70V
-
Channel Capacitance (CS(off), CD(off)):
35pF
-
Mounting Type:
Surface Mount
-
Series:
-
-
Crosstalk:
-96dB @ 10MHz
-
Number of Circuits:
4
-
Current - Leakage (IS(off)) (Max):
2.5nA
-
Base Part Number:
MAX14757
-
detail:
4 Circuit IC Switch 1:1 10Ohm 16-TSSOP
