TDA8950 دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
TDA8950
|
|
حجم فایل
|
238.219
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
39
|
مشخصات فنی
-
Manufacturer:
NXP USA Inc.
-
Series:
-
-
Packaging:
Tube
-
Part Status:
Not For New Designs
-
Type:
Class D
-
Output Type:
1-Channel (Mono) or 2-Channel (Stereo)
-
Max Output Power x Channels @ Load:
340W x 1 @ 8Ohm; 170W x 2 @ 4Ohm
-
Voltage - Supply:
±12.5V ~ 40V
-
Features:
Depop, Differential Inputs, Mute, Short-Circuit and Thermal Protection, Standby
-
Mounting Type:
Through Hole
-
Operating Temperature:
-40°C ~ 85°C (TA)
-
Supplier Device Package:
DBS23P
-
Package / Case:
23-SIP Formed Leads
-
Base Part Number:
TDA895
-
detail:
Amplifier IC 1-Channel (Mono) or 2-Channel (Stereo) Class D DBS23P
