- دیتاشیت MAX14752EUE+T
MAX14752EUE+T دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | MAX14752EUE+T |
|---|---|
| حجم فایل | 80.633 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 16 |
دانلود دیتاشیت MAX14752EUE+T |
دانلود دیتاشیت |
|---|
سایر مستندات
Part Numbering System 7 pages
MAX14752,53 15 pages
مشخصات فنی
- RoHS: true
- Category: Logic ICs/Signal Switches / Encoders & Decoders / Multiplexers
- Datasheet: Analog Devices Inc./Maxim Integrated MAX14752EUE+T
- Package: TSSOP-16
- Manufacturer: Analog Devices Inc./Maxim Integrated
- Multiplexer/Demultiplexer Circuit: 8:1
- Part Status: Active
- Charge Injection: 200pC
- -3db Bandwidth: 20MHz
- Operating Temperature: -40°C ~ 85°C (TA)
- Voltage - Supply, Dual (V±): ±10V ~ 36V
- Supplier Device Package: 16-TSSOP
- Package / Case: 16-TSSOP (0.173", 4.40mm Width)
- Switch Time (Ton, Toff) (Max): 25µs, 2µs
- Packaging: Cut Tape (CT)
- Channel-to-Channel Matching (ΔRon): 500mOhm
- Voltage - Supply, Single (V+): 20V ~ 72V
- Channel Capacitance (CS(off), CD(off)): 3.7pF
- Switch Circuit: -
- Mounting Type: Surface Mount
- Series: -
- Crosstalk: -62dB @ 100kHz
- Number of Circuits: 1
- Current - Leakage (IS(off)) (Max): 20nA
- Base Part Number: MAX14752
- On-State Resistance (Max): 130Ohm
- detail: 1 Circuit IC Switch 8:1 130Ohm 16-TSSOP
