- دیتاشیت MK30DX128VLL7
MK30DX128VLL7 دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | MK30DX128VLL7 |
|---|---|
| حجم فایل | 73.394 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 70 |
دانلود دیتاشیت MK30DX128VLL7 |
دانلود دیتاشیت |
|---|
سایر مستندات
K30_LL/MC7 Ref Manual 1377 pages
مشخصات فنی
- RoHS: true
- EEPROM: -
- CPU Core: ARM Cortex-M4
- Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
- RAM Size: -
- Watchdog: Yes
- ADC (Bit): 16bit
- DAC (Bit): 12bit
- Datasheet: NXP Semicon MK30DX128VLL7
- PWM (Bit): -
- LCD Module: Yes
- Real-Time Clock: -
- CPU Maximum Speed: 72MHz
- GPIO Ports Number: 70
- Low-Voltage Detect: Yes
- CCP Capture/Compare: -
- Internal Comparator: -
- Internal Oscillator: Yes
- Peripheral/Function: DMA
- Program Memory Type: FLASH
- Direct Memory Access: Yes
- Program Storage Size: 128KB
- Universal Serial Bus: -
- communication protocol: -
- Operating Voltage Range: 1.71V~3.6V
- Infrared Data Association: Yes
- Operating Temperature Range: -40°C~+105°C
- Secure Digital Input and Output: -
- Package: LQFP-100(14x14)
- Manufacturer: NXP Semicon
- Series: Kinetis K30
- Packaging: Tray
- Part Status: Active
- Core Processor: ARM® Cortex®-M4
- Core Size: 32-Bit
- Speed: 72MHz
- Connectivity: CANbus, I²C, IrDA, SD, SPI, UART/USART
- Peripherals: DMA, I²S, LCD, LVD, POR, PWM, WDT
- Number of I/O: 70
- Program Memory Size: 128KB (128K x 8)
- EEPROM Size: 2K x 8
- Voltage - Supply (Vcc/Vdd): 1.71V ~ 3.6V
- Data Converters: A/D 38x16b; D/A 1x12b
- Oscillator Type: Internal
- Operating Temperature: -40°C ~ 105°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 100-LQFP
- Supplier Device Package: 100-LQFP (14x14)
- Base Part Number: MK30
- detail: ARM® Cortex®-M4 Kinetis K30 Microcontroller IC 32-Bit 72MHz 128KB (128K x 8) FLASH 100-LQFP (14x14)
