MIMXRT1064CVL5A دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | MIMXRT1064CVL5A |
|---|---|
| حجم فایل | 96.338 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 115 |
دانلود دیتاشیت MIMXRT1064CVL5A |
دانلود دیتاشیت |
|---|
سایر مستندات
MIMXRT1064CVx5A 111 pages
MiMXRT1064 Errata 21 pages
مشخصات فنی
- CAN: -
- I2C: -
- I2S: -
- SPI: -
- RoHS: true
- EEPROM: -
- CPU Core: ARM-MSeries
- Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
- RAM Size: 1MB
- Watchdog: Yes
- ADC (Bit): 12bit
- DAC (Bit): -
- Datasheet: NXP Semicon MIMXRT1064CVL5A
- PWM (Bit): -
- 8Bit Timer: -
- UART/USART: -
- 16Bit Timer: -
- 32Bit Timer: -
- Real-Time Clock: -
- CPU Maximum Speed: 528MHz
- GPIO Ports Number: 127
- Low-Voltage Detect: -
- CCP Capture/Compare: -
- Internal Comparator: -
- Internal Oscillator: -
- Peripheral/Function: Ethernet protocol stack;SDIO;WDT;DMA;PWM
- Program Memory Type: FLASH
- Direct Memory Access: Yes
- Program Storage Size: 4MB
- Universal Serial Bus: Yes
- communication protocol: 以太网协议
- Operating Voltage Range: 3V~3.6V
- Infrared Data Association: -
- Operating Temperature Range: -40°C~+105°C
- Secure Digital Input and Output: Yes
- Package: MAPBGA-196
- Manufacturer: NXP Semicon
- Series: RT1060
- Packaging: Tray
- Part Status: Active
- Core Processor: ARM® Cortex®-M7
- Core Size: 32-Bit
- Speed: 528MHz
- Connectivity: CANbus, EBI/EMI, Ethernet, I²C, MMC/SD/SDIO, SAI, SPDIF, SPI, UART/USART, USB OTG
- Peripherals: Brown-out Detect/Reset, DMA, POR, PWM, WDT
- Number of I/O: 127
- Program Memory Size: 4MB (4M x 8)
- EEPROM Size: -
- Voltage - Supply (Vcc/Vdd): 3V ~ 3.6V
- Data Converters: A/D 20x12b
- Oscillator Type: Internal/External
- Operating Temperature: -40°C ~ 105°C (TJ)
- Mounting Type: Surface Mount
- Package / Case: 196-LFBGA
- Supplier Device Package: 196-MAPBGA (10x10)
- Base Part Number: MIMXRT10
- detail: ARM® Cortex®-M7 RT1060 Microcontroller IC 32-Bit 528MHz 4MB (4M x 8) FLASH 196-MAPBGA (10x10)
