MC9S08QL(8,4) Datasheet دیتاشیت

مشخصات دیتاشیت

دانلود دیتاشیت MC9S08QL(8,4) Datasheet	دانلود دیتاشیت

RoHS: true
EEPROM: -
CPU Core: Other series
Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
RAM Size: -
Watchdog: Yes
ADC (Bit): 12bit
DAC (Bit): -
Datasheet: NXP Semicon MC9S08QL8CTJ
PWM (Bit): -
Real-Time Clock: -
CPU Maximum Speed: 20MHz
GPIO Ports Number: 18
Low-Voltage Detect: Yes
CCP Capture/Compare: -
Internal Comparator: -
Internal Oscillator: Yes
Peripheral/Function: WDT
Program Memory Type: FLASH
Direct Memory Access: -
Program Storage Size: 8KB
Universal Serial Bus: -
communication protocol: -
Operating Voltage Range: 1.8V~3.6V
Infrared Data Association: -
Operating Temperature Range: -40°C~+85°C
Secure Digital Input and Output: -
Package: TSSOP-20
Manufacturer: NXP Semicon
Series: S08
Packaging: Tube
Part Status: Active
Core Processor: S08
Core Size: 8-Bit
Speed: 20MHz
Connectivity: LINbus, SCI
Peripherals: LVD, PWM, WDT
Number of I/O: 18
Program Memory Size: 8KB (8K x 8)
EEPROM Size: -
Voltage - Supply (Vcc/Vdd): 1.8V ~ 3.6V
Data Converters: A/D 8x12b
Oscillator Type: Internal
Operating Temperature: -40°C ~ 85°C (TA)
Mounting Type: Surface Mount
Package / Case: 20-TSSOP (0.173", 4.40mm Width)
Supplier Device Package: 20-TSSOP
Base Part Number: MC9S0
detail: S08 S08 Microcontroller IC 8-Bit 20MHz 8KB (8K x 8) FLASH 20-TSSOP
