- دیتاشیت MAX333CPP+
MAX333CPP+ دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | MAX333CPP+ |
|---|---|
| حجم فایل | 71.784 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 4 |
دانلود دیتاشیت MAX333CPP+ |
دانلود دیتاشیت |
|---|
سایر مستندات
Part Numbering System 7 pages
MAX333 4 pages
مشخصات فنی
- RoHS: true
- Category: Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
- Datasheet: Analog Devices Inc./Maxim Integrated MAX333CPP+
- Switch Circuit: -
- Package: PDIP-20
- Manufacturer: Analog Devices Inc./Maxim Integrated
- Multiplexer/Demultiplexer Circuit: 2:1
- Part Status: Active
- Charge Injection: -
- -3db Bandwidth: -
- Operating Temperature: 0°C ~ 70°C (TA)
- Voltage - Supply, Dual (V±): ±5V ~ 18V
- Supplier Device Package: 20-PDIP
- Package / Case: 20-DIP (0.300", 7.62mm)
- Switch Time (Ton, Toff) (Max): 1µs, 500ns
- Packaging: Tube
- Channel-to-Channel Matching (ΔRon): -
- Voltage - Supply, Single (V+): 10V ~ 30V
- Channel Capacitance (CS(off), CD(off)): 5pF
- Mounting Type: Through Hole
- Series: -
- Crosstalk: -78dB @ 1MHz
- Number of Circuits: 4
- Current - Leakage (IS(off)) (Max): 5nA
- Base Part Number: MAX333
- On-State Resistance (Max): 250Ohm
- detail: 4 Circuit IC Switch 2:1 250Ohm 20-PDIP
