دیتاشیت TEA1723FT/N1,118

TEA1723FT

مشخصات دیتاشیت

نام دیتاشیت TEA1723FT
حجم فایل 252.736 کیلوبایت
نوع فایل pdf
تعداد صفحات 14

دانلود دیتاشیت TEA1723FT

TEA1723FT Datasheet

مشخصات

  • Manufacturer: NXP USA Inc.
  • Series: GreenChip™
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Output Isolation: Non-Isolated
  • Internal Switch(s): Yes
  • Voltage - Breakdown: 700V
  • Topology: Flyback
  • Voltage - Start Up: 17V
  • Voltage - Supply (Vcc/Vdd): 8.5V ~ 20V
  • Duty Cycle: 75%
  • Frequency - Switching: 22.5kHz ~ 50.5kHz
  • Power (Watts): 11W
  • Fault Protection: Over Temperature, Over Voltage, Short Circuit
  • Control Features: -
  • Operating Temperature: -40°C ~ 85°C (TA)
  • Package / Case: 8-SOIC (0.154", 3.90mm Width), 7 Leads
  • Supplier Device Package: 7-SO
  • Mounting Type: Surface Mount
  • Base Part Number: TEA172
  • detail: Converter Offline Flyback Topology 22.5kHz ~ 50.5kHz 7-SO
