MAX17575ATC+T دیتاشیت

مشخصات دیتاشیت

دانلود دیتاشیت MAX17575ATC+T	دانلود دیتاشیت

RoHS: true
Category: Power Supply Chip/DC-DC Converters
Function: Step-down type
Topology: Step-down
Datasheet: Analog Devices Inc./Maxim Integrated MAX17575ATC+T
Output Type: Adjustable
Input Voltage: 4.5V~60V
Output Voltage: 0.9V~54V
Number of Outputs: 1
Switching Frequency: 2.2MHz
Output Current (Max): 1.5A
Operating Temperature: -40°C~+125°C@(TA)
Synchronous Rectification: NO
Package: DFN-12(3x3)
Manufacturer: Analog Devices Inc./Maxim Integrated
Voltage - Input (Max): 60V
Voltage - Input (Min): 4.5V
Output Configuration: Positive
Supplier Device Package: 12-TDFN (3x3)
Package / Case: 12-WFDFN Exposed Pad
Frequency - Switching: 400kHz ~ 2.2MHz
Current - Output: 1.5A
Part Status: Active
Series: -
Voltage - Output (Max): 54V
Base Part Number: MAX17575
Mounting Type: Surface Mount
Synchronous Rectifier: No
Voltage - Output (Min/Fixed): 0.9V
Packaging: Cut Tape (CT)
detail: Buck Switching Regulator IC Positive Adjustable 0.9V 1 Output 1.5A 12-WFDFN Exposed Pad
