MPVZ5010GW7U دیتاشیت

مشخصات دیتاشیت

دانلود دیتاشیت MPVZ5010GW7U	دانلود دیتاشیت

Manufacturer: NXP USA Inc.
Series: MPVZ5010G
Part Status: Active
Applications: Board Mount
Pressure Type: Vented Gauge
Operating Pressure: 1.45PSI (10kPa)
Output Type: Analog Voltage
Output: 0.2 V ~ 4.7 V
Accuracy: -
Voltage - Supply: 4.75V ~ 5.25V
Port Size: Male - 0.22" (5.59mm) Tube
Port Style: Barbless
Features: Temperature Compensated
Termination Style: PC Pin
Maximum Pressure: 5.8PSI (40kPa)
Operating Temperature: -40°C ~ 125°C
Package / Case: 8-DIP Module
Supplier Device Package: -
Base Part Number: MPVZ5
detail: Pressure Sensor 1.45PSI (10kPa) Vented Gauge Male - 0.22" (5.59mm) Tube 0.2 V ~ 4.7 V 8-DIP Module
