MCIMX7D2D Datasheet دیتاشیت

MCIMX7D2D Datasheet

مشخصات دیتاشیت

نام دیتاشیت MCIMX7D2D Datasheet
حجم فایل 1930.423 کیلوبایت
نوع فایل pdf
تعداد صفحات 158

مشاهده دیتاشیت MCIMX7D2D Datasheet

دانلود دیتاشیت

سایر مستندات

MCIMX7D2DVM12SD 158 pages

مشخصات فنی

  • CAN: -
  • I2C: 4
  • I2S: -
  • SPI: 4
  • RoHS: true
  • EEPROM: -
  • CPU Core: ARM Cortex-A7;ARM Cortex-M4
  • Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
  • RAM Size: 256KB
  • Watchdog: -
  • ADC (Bit): -
  • DAC (Bit): -
  • Datasheet: NXP Semicon MCIMX7D5EVM10SD
  • PWM (Bit): -
  • 8Bit Timer: -
  • LCD Module: Yes
  • LED Module: -
  • UART/USART: 7
  • 16Bit Timer: -
  • 32Bit Timer: -
  • Real-Time Clock: -
  • Application Area: -
  • CPU Maximum Speed: 1000MHz
  • GPIO Ports Number: -
  • Low-Voltage Detect: -
  • CCP Capture/Compare: -
  • Internal Comparator: -
  • Internal Oscillator: -
  • Peripheral/Function: -
  • Program Memory Type: -
  • Direct Memory Access: -
  • Program Storage Size: -
  • Universal Serial Bus: Yes
  • communication protocol: -
  • Operating Voltage Range: -
  • Infrared Data Association: -
  • Operating Temperature Range: -20°C~+105°C
  • Secure Digital Input and Output: -
  • Package: MAPBGA-541
  • Manufacturer: NXP Semicon
  • Series: i.MX7D
  • Packaging: Tray
  • Part Status: Active
  • Core Processor: ARM® Cortex®-A7, ARM® Cortex®-M4
  • Number of Cores/Bus Width: 2 Core, 32-Bit
  • Speed: 1.0GHz
  • Co-Processors/DSP: Multimedia; NEON™ MPE
  • RAM Controllers: LPDDR2, LPDDR3, DDR3, DDR3L
  • Graphics Acceleration: No
  • Display & Interface Controllers: Keypad, LCD, MIPI
  • Ethernet: 10/100/1000Mbps (2)
  • SATA: -
  • USB: USB 2.0 + PHY (1), USB 2.0 OTG + PHY (2)
  • Voltage - I/O: 1.8V, 3.3V
  • Operating Temperature: -20°C ~ 105°C (TJ)
  • Security Features: A-HAB, ARM TZ, CAAM, CSU, SJC, SNVS
  • Package / Case: 541-LFBGA
  • Supplier Device Package: 541-MAPBGA (19x19)
  • Additional Interfaces: AC'97, CAN, eCSPI, I²C, I²S, MMC/SD/SDIO, PCIe, QSPI, SAI, UART
  • Base Part Number: MCIMX7
  • detail: ARM® Cortex®-A7, ARM® Cortex®-M4 Microprocessor IC i.MX7D 2 Core, 32-Bit 1.0GHz 541-MAPBGA (19x19)
