MAX680CPA+ دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت MAX680CPA+	دانلود دیتاشیت

RoHS: true
Category: Power Supply Chip/DC-DC Converters
Function: -
Topology: -
Datasheet: Analog Devices Inc./Maxim Integrated MAX680CPA+
Output Type: Fixed
Input Voltage: 2V~6V
Output Voltage: 10V;-10V
Number of Outputs: 2
Switching Frequency: 8kHz
Output Current (Max): 10mA
Operating Temperature: 0°C~+70°C@(TA)
Synchronous Rectification: NO
Package: DIP-8
Manufacturer: Analog Devices Inc./Maxim Integrated
Voltage - Input (Max): 6V
Voltage - Input (Min): 2V
Output Configuration: Positive and Negative (Dual Rail)
Supplier Device Package: 8-PDIP
Package / Case: 8-DIP (0.300", 7.62mm)
Frequency - Switching: 8kHz
Current - Output: 10mA
Part Status: Active
Series: -
Voltage - Output (Max): -
Base Part Number: MAX680
Mounting Type: Through Hole
Synchronous Rectifier: No
Voltage - Output (Min/Fixed): ±2Vin
Packaging: Tube
detail: Charge Pump Switching Regulator IC Positive and Negative (Dual Rail) Fixed ±2Vin 2 Output 10mA 8-DIP (0.300", 7.62mm)
