MSC70SM120JCU2 دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
MSC70SM120JCU2
|
|
حجم فایل
|
1380.54
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
14
|
مشخصات فنی
-
Manufacturer:
Microchip Technology
-
Series:
-
-
Part Status:
Active
-
FET Type:
N-Channel
-
Technology:
SiC (Silicon Carbide Junction Transistor)
-
Drain to Source Voltage (Vdss):
1.2kV
-
Current - Continuous Drain (Id) @ 25°C:
89A (Tc)
-
Drive Voltage (Max Rds On, Min Rds On):
20V
-
Rds On (Max) @ Id, Vgs:
31mOhm @ 40A, 20V
-
Vgs(th) (Max) @ Id:
2.8V @ 1mA
-
Gate Charge (Qg) (Max) @ Vgs:
232nC @ 20V
-
Vgs (Max):
+25V, -10V
-
Input Capacitance (Ciss) (Max) @ Vds:
3020pF/m @ 1000V
-
FET Feature:
-
-
Power Dissipation (Max):
395W (Tc)
-
Operating Temperature:
-55°C ~ 150°C (TJ)
-
Mounting Type:
Chassis Mount
-
Supplier Device Package:
SOT-227 (ISOTOP®)
-
Package / Case:
SOT-227-4, miniBLOC
-
detail:
N-Channel 1.2kV 89A (Tc) 395W (Tc) Chassis Mount SOT-227 (ISOTOP®)
