MSCDC150A70D1PAG دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
MSCDC150A70D1PAG
|
|
حجم فایل
|
701.603
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
6
|
مشخصات فنی
-
Manufacturer:
Microchip Technology
-
Series:
-
-
Part Status:
Active
-
Diode Configuration:
1 Pair Series Connection
-
Diode Type:
Silicon Carbide Schottky
-
Voltage - DC Reverse (Vr) (Max):
700V
-
Current - Average Rectified (Io) (per Diode):
150A (DC)
-
Voltage - Forward (Vf) (Max) @ If:
1.8V @ 150A
-
Speed:
No Recovery Time > 500mA (Io)
-
Reverse Recovery Time (trr):
0ns
-
Current - Reverse Leakage @ Vr:
600µA @ 150A
-
Operating Temperature - Junction:
-40°C ~ 175°C
-
Mounting Type:
Chassis Mount
-
Package / Case:
Module
-
Supplier Device Package:
D1P
-
detail:
Diode Array 1 Pair Series Connection Silicon Carbide Schottky 700V 150A (DC) Chassis Mount Module
