دیتاشیت TEA1833TS/1H

TEA1833TS

مشخصات دیتاشیت

نام دیتاشیت TEA1833TS
حجم فایل 256.208 کیلوبایت
نوع فایل pdf
تعداد صفحات 24

دانلود دیتاشیت TEA1833TS

TEA1833TS Datasheet

مشخصات

  • RoHS: true
  • Category: Power Supply Chip/AC-DC Controllers & Regulators
  • Topology: Flyback
  • Datasheet: NXP Semicon TEA1833TS/1H
  • Duty Cycle: 90%
  • Supply Voltage: 10.5V~36V
  • Output Isolation: Isolation
  • Switching Frequency: 65kHz
  • Operating Temperature: -40°C~+150°C@(Tj)
  • Package: SOT-23-6
  • Manufacturer: NXP Semicon
  • Series: GreenChip™
  • Packaging: Tape & Reel (TR)
  • Part Status: Active
  • Internal Switch(s): No
  • Voltage - Breakdown: -
  • Voltage - Start Up: 22V
  • Voltage - Supply (Vcc/Vdd): 10.5V ~ 36V
  • Frequency - Switching: 65kHz
  • Fault Protection: Over Power, Over Temperature, Over Voltage, Short Circuit
  • Control Features: -
  • Package / Case: SC-74, SOT-457
  • Supplier Device Package: 6-TSOP
  • Mounting Type: Surface Mount
  • Base Part Number: TEA183
  • detail: Converter Offline Flyback Topology 65kHz 6-TSOP
