- دیتاشیت MC9S08SH8, MC9S08SH4 Datasheet
MC9S08SH8, MC9S08SH4 Datasheet دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | MC9S08SH8, MC9S08SH4 Datasheet |
|---|---|
| حجم فایل | 3789.968 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 343 |
دانلود دیتاشیت MC9S08SH8, MC9S08SH4 Datasheet |
دانلود دیتاشیت |
|---|
سایر مستندات
MC9S08SH8, 4 Fact Sheet 2 pages
MC9S08SH8MTG 316 pages
مشخصات فنی
- CAN: -
- I2C: -
- I2S: -
- SPI: -
- RoHS: true
- EEPROM: -
- CPU Core: Other series
- Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
- RAM Size: 512Byte
- Watchdog: Yes
- ADC (Bit): 10bit
- DAC (Bit): -
- Datasheet: NXP Semicon MC9S08SH8MTGR
- PWM (Bit): -
- 8Bit Timer: -
- UART/USART: -
- 16Bit Timer: -
- 32Bit Timer: -
- Real-Time Clock: -
- CPU Maximum Speed: 40MHz
- GPIO Ports Number: 13
- Low-Voltage Detect: Yes
- CCP Capture/Compare: -
- Internal Comparator: -
- Internal Oscillator: Yes
- Peripheral/Function: LIN(Local Interconnect Network)
- Program Memory Type: FLASH
- Direct Memory Access: -
- Program Storage Size: 8KB
- Universal Serial Bus: -
- communication protocol: -
- Operating Voltage Range: 2.7V~5.5V
- Infrared Data Association: -
- Operating Temperature Range: -40°C~+125°C
- Secure Digital Input and Output: -
- Package: TSSOP-16
- Manufacturer: NXP Semicon
- Series: S08
- Packaging: Tape & Reel (TR)
- Part Status: Active
- Core Processor: S08
- Core Size: 8-Bit
- Speed: 40MHz
- Connectivity: I²C, LINbus, SCI, SPI
- Peripherals: LVD, POR, PWM, WDT
- Number of I/O: 13
- Program Memory Size: 8KB (8K x 8)
- EEPROM Size: -
- Voltage - Supply (Vcc/Vdd): 2.7V ~ 5.5V
- Data Converters: A/D 8x10b
- Oscillator Type: Internal
- Operating Temperature: -40°C ~ 125°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 16-TSSOP (0.173", 4.40mm Width)
- Supplier Device Package: 16-TSSOP
- Base Part Number: MC9S0
- detail: S08 S08 Microcontroller IC 8-Bit 40MHz 8KB (8K x 8) FLASH 16-TSSOP
