MC9S08QA2,4 Ref Manual دیتاشیت

MC9S08QA2,4 Ref Manual

مشخصات دیتاشیت

نام دیتاشیت MC9S08QA2,4 Ref Manual
حجم فایل 1639.745 کیلوبایت
نوع فایل pdf
تعداد صفحات 32

مشاهده دیتاشیت MC9S08QA2,4 Ref Manual

دانلود دیتاشیت

سایر مستندات

MC9S08QA4CFQE 32 pages

مشخصات فنی

  • CAN: -
  • I2C: -
  • I2S: -
  • SPI: -
  • RoHS: true
  • EEPROM: -
  • CPU Core: Other series
  • Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
  • RAM Size: 160Byte
  • Watchdog: Yes
  • ADC (Bit): 10bit
  • DAC (Bit): -
  • Datasheet: NXP Semicon MC9S08QA2CPAE
  • PWM (Bit): -
  • 8Bit Timer: -
  • UART/USART: -
  • 16Bit Timer: -
  • 32Bit Timer: -
  • Real-Time Clock: -
  • CPU Maximum Speed: 20MHz
  • GPIO Ports Number: 4
  • Low-Voltage Detect: Yes
  • CCP Capture/Compare: -
  • Internal Comparator: -
  • Internal Oscillator: Yes
  • Peripheral/Function: WDT;Low-VoltageDetect;PWM
  • Program Memory Type: FLASH
  • Direct Memory Access: -
  • Program Storage Size: 2KB
  • Universal Serial Bus: -
  • communication protocol: -
  • Operating Voltage Range: 1.8V~3.6V
  • Infrared Data Association: -
  • Operating Temperature Range: -40°C~+85°C
  • Secure Digital Input and Output: -
  • Package: PDIP-8
  • Manufacturer: NXP Semicon
  • Series: S08
  • Packaging: Tube
  • Part Status: Active
  • Core Processor: S08
  • Core Size: 8-Bit
  • Speed: 20MHz
  • Connectivity: -
  • Peripherals: LVD, POR, PWM, WDT
  • Number of I/O: 4
  • Program Memory Size: 2KB (2K x 8)
  • EEPROM Size: -
  • Voltage - Supply (Vcc/Vdd): 1.8V ~ 3.6V
  • Data Converters: A/D 4x10b
  • Oscillator Type: Internal
  • Operating Temperature: -40°C ~ 85°C (TA)
  • Mounting Type: Through Hole
  • Package / Case: 8-DIP (0.300", 7.62mm)
  • Supplier Device Package: 8-PDIP
  • Base Part Number: MC9S0
  • detail: S08 S08 Microcontroller IC 8-Bit 20MHz 2KB (2K x 8) FLASH 8-PDIP
