MC9S08AC32CFGER دیتاشیت

مشخصات دیتاشیت

دانلود دیتاشیت MC9S08AC32CFGER	دانلود دیتاشیت

RoHS: true
CPU Core: Other series
Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
Watchdog: Yes
ADC (Bit): 10bit
Datasheet: NXP Semicon MC9S08AC32CFGER
CPU Maximum Speed: 40MHz
GPIO Ports Number: 34
Low-Voltage Detect: Yes
Internal Oscillator: Yes
Program Storage Size: 32KB
Operating Voltage Range: 2.7V~5.5V
Operating Temperature Range: -40°C~+85°C
Package: LQFP-44(10x10)
Manufacturer: NXP Semicon
Series: S08
Packaging: Cut Tape (CT)
Part Status: Discontinued at Digi-Key
Core Processor: S08
Core Size: 8-Bit
Speed: 40MHz
Connectivity: I²C, SCI, SPI
Peripherals: LVD, POR, PWM, WDT
Number of I/O: 34
Program Memory Size: 32KB (32K x 8)
Program Memory Type: FLASH
EEPROM Size: -
RAM Size: 2K x 8
Voltage - Supply (Vcc/Vdd): 2.7V ~ 5.5V
Data Converters: A/D 8x10b
Oscillator Type: Internal
Operating Temperature: -40°C ~ 85°C (TA)
Mounting Type: Surface Mount
Package / Case: 44-LQFP
Supplier Device Package: 44-LQFP (10x10)
Base Part Number: MC9S0
detail: S08 S08 Microcontroller IC 8-Bit 40MHz 32KB (32K x 8) FLASH 44-LQFP (10x10)
