- دیتاشیت S912ZVLA64F0MLF
S912ZVLA64F0MLF دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | S912ZVLA64F0MLF |
|---|---|
| حجم فایل | 53.44 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 2 |
دانلود دیتاشیت S912ZVLA64F0MLF |
دانلود دیتاشیت |
|---|
سایر مستندات
MC9S12ZVL Family Ref Manual, Datasheet 783 pages
مشخصات فنی
- RoHS: true
- EEPROM: -
- CPU Core: Other series
- Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
- RAM Size: 1KB
- Watchdog: -
- ADC (Bit): 10bit
- DAC (Bit): 8bit
- Datasheet: NXP Semicon S912ZVLA64F0MLF
- PWM (Bit): -
- Real-Time Clock: -
- CPU Maximum Speed: 32MHz
- GPIO Ports Number: 34
- Low-Voltage Detect: -
- CCP Capture/Compare: -
- Internal Comparator: -
- Internal Oscillator: Yes
- Peripheral/Function: Low-VoltageDetect;WDT
- Program Memory Type: FLASH
- Direct Memory Access: -
- Program Storage Size: 64KB
- Universal Serial Bus: -
- communication protocol: -
- Operating Voltage Range: 5.5V~18V
- Infrared Data Association: -
- Operating Temperature Range: -40°C~+125°C
- Secure Digital Input and Output: -
- Package: LQFP-48(7x7)
- Manufacturer: NXP Semicon
- Series: S12 MagniV
- Packaging: Bulk
- Part Status: Active
- Core Processor: S12Z
- Core Size: 16-Bit
- Speed: 32MHz
- Connectivity: CANbus, I²C, IrDA, LINbus, SCI, SPI, UART/USART
- Peripherals: LVD, POR, PWM, WDT
- Number of I/O: 34
- Program Memory Size: 64KB (64K x 8)
- EEPROM Size: 512 x 8
- Voltage - Supply (Vcc/Vdd): 5.5V ~ 18V
- Data Converters: A/D 10x10b; D/A 1x8b
- Oscillator Type: Internal
- Operating Temperature: -40°C ~ 125°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 48-LQFP
- Supplier Device Package: 48-LQFP (7x7)
- Base Part Number: S912
- detail: S12Z S12 MagniV Microcontroller IC 16-Bit 32MHz 64KB (64K x 8) FLASH 48-LQFP (7x7)
