دیتاشیت TC1054-2.85VCT713
مشخصات دیتاشیت
| نام دیتاشیت | TC1054, 1055, 1186 |
|---|---|
| حجم فایل | 445.854 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 20 |
دانلود دیتاشیت TC1054, 1055, 1186 |
TC1054, 1055, 1186 Datasheet |
|---|
مشخصات
- Manufacturer: Microchip Technology
- Series: -
- Packaging: Tape & Reel (TR)
- Part Status: Active
- Output Configuration: Positive
- Output Type: Fixed
- Number of Regulators: 1
- Voltage - Input (Max): 6.5V
- Voltage - Output (Min/Fixed): 2.85V
- Voltage - Output (Max): -
- Voltage Dropout (Max): 0.12V @ 50mA
- Current - Output: 50mA
- Current - Quiescent (Iq): 80µA
- PSRR: 64dB (1kHz)
- Control Features: Enable
- Protection Features: Over Current, Over Temperature
- Operating Temperature: -40°C ~ 125°C
- Mounting Type: Surface Mount
- Package / Case: SC-74A, SOT-753
- Supplier Device Package: SOT-23-5
- Base Part Number: TC1054
- detail: Linear Voltage Regulator IC 1 Output 50mA SOT-23-5
