- دیتاشیت MAX16910CASA8+
MAX16910CASA8+ دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | MAX16910CASA8+ |
|---|---|
| حجم فایل | 81.505 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 15 |
دانلود دیتاشیت MAX16910CASA8+ |
دانلود دیتاشیت |
|---|
سایر مستندات
Part Numbering System 7 pages
MAX16910 15 pages
مشخصات فنی
- RoHS: true
- Category: Power Supply Chip/Linear Voltage Regulators (LDO)
- Datasheet: Analog Devices Inc./Maxim Integrated MAX16910CASA8+
- Output Type: -
- Output Current: 200mA
- Output Voltage: 1.5V~11V
- Dropout Voltage: 0.6V@(200mA)
- Output Polarity: positive
- Number of Outputs: 1
- Maximum Input Voltage: 35V
- Operating Temperature: -40°C~+125°C@(Ta)
- Quiescent Current (Ground Current): 30uA
- Power Supply Rejection Ratio (PSRR): 60dB@(100Hz)
- Package: SO-8-EP
- Manufacturer: Analog Devices Inc./Maxim Integrated
- Voltage Dropout (Max): 0.6V @ 200mA
- PSRR: 60dB (100Hz)
- Current - Quiescent (Iq): 30µA
- Supplier Device Package: 8-SOIC-EP
- Mounting Type: Surface Mount
- Voltage - Input (Max): 30V
- Output Configuration: Positive
- Protection Features: Over Temperature, Short Circuit
- Current - Output: 200mA
- Number of Regulators: 1
- Series: -
- Voltage - Output (Max): 11V
- Part Status: Active
- Package / Case: 8-SOIC (0.154", 3.90mm Width) Exposed Pad
- Voltage - Output (Min/Fixed): 1.5V (3.3V, 5V)
- Packaging: Tube
- Control Features: Enable, Reset
- Base Part Number: MAX16910
- detail: Linear Voltage Regulator IC 1 Output 200mA 8-SOIC-EP
