MAX4719EUB+ دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | MAX4719EUB+ |
|---|---|
| حجم فایل | 95.032 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 11 |
دانلود دیتاشیت MAX4719EUB+ |
دانلود دیتاشیت |
|---|
سایر مستندات
Part Numbering System 7 pages
MAX4719 11 pages
مشخصات فنی
- RoHS: true
- Category: Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
- Datasheet: Analog Devices Inc./Maxim Integrated MAX4719EUB+
- Turn-on time: 80ns
- Turn-off time: 40ns
- Supply Voltage: 1.8V~5.5V
- Switch Circuit: SPDT(SPDT)
- Number of Channels: 2
- On-State Resistance (Max): 20Ω
- Package: UMAX-10
- Manufacturer: Analog Devices Inc./Maxim Integrated
- Multiplexer/Demultiplexer Circuit: 2:1
- Part Status: Active
- Charge Injection: 18pC
- -3db Bandwidth: 300MHz
- Operating Temperature: -40°C ~ 85°C (TA)
- Voltage - Supply, Dual (V±): -
- Supplier Device Package: 10-uMAX
- Package / Case: 10-TFSOP, 10-MSOP (0.118", 3.00mm Width)
- Switch Time (Ton, Toff) (Max): 80ns, 40ns
- Packaging: Tube
- Channel-to-Channel Matching (ΔRon): 150mOhm
- Voltage - Supply, Single (V+): 1.8V ~ 5.5V
- Channel Capacitance (CS(off), CD(off)): 9pF
- Mounting Type: Surface Mount
- Series: -
- Crosstalk: -110dB @ 1MHz
- Number of Circuits: 2
- Current - Leakage (IS(off)) (Max): 500pA
- Base Part Number: MAX4719
- detail: 2 Circuit IC Switch 2:1 20Ohm 10-uMAX
