دیتاشیت TC2186-3.3VCTTR
مشخصات دیتاشیت
| نام دیتاشیت | TC2054, 2055, 2186 |
|---|---|
| حجم فایل | 430.727 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 22 |
دانلود دیتاشیت TC2054, 2055, 2186 |
TC2054, 2055, 2186 Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/Linear Voltage Regulators (LDO)
- Datasheet: Microchip Tech TC2186-3.3VCTTR
- Output Current: 150mA
- Output Voltage: 3.3V
- Dropout Voltage: 0.21V@(150mA)
- Output Polarity: positive
- Number of Outputs: 1
- Maximum Input Voltage: 6V
- Operating Temperature: -40°C~+125°C
- Quiescent Current (Ground Current): 80uA
- Power Supply Rejection Ratio (PSRR): 50dB@(100kHz)
- Package: SOT-23-5
- Manufacturer: Microchip Tech
- Series: -
- Packaging: Tape & Reel (TR)
- Part Status: Active
- Output Configuration: Positive
- Output Type: Fixed
- Number of Regulators: 1
- Voltage - Input (Max): 6V
- Voltage - Output (Min/Fixed): 3.3V
- Voltage - Output (Max): -
- Voltage Dropout (Max): 0.21V @ 150mA
- Current - Output: 150mA
- Current - Quiescent (Iq): 80µA
- PSRR: 50dB (100kHz)
- Control Features: Enable
- Protection Features: Over Current, Over Temperature
- Mounting Type: Surface Mount
- Package / Case: SC-74A, SOT-753
- Supplier Device Package: SOT-23-5
- Base Part Number: TC2186
- detail: Linear Voltage Regulator IC 1 Output 150mA SOT-23-5
