دیتاشیت ADC1413D105HN/C1:5

مشخصات دیتاشیت

دانلود دیتاشیت ADC1413D Series	ADC1413D Series Datasheet

Manufacturer: NXP USA Inc.
Series: -
Packaging: Tray
Part Status: Not For New Designs
Number of Bits: 14
Sampling Rate (Per Second): 105M
Number of Inputs: 2
Input Type: Differential, Single Ended
Data Interface: JESD204A
Configuration: S/H-ADC
Ratio - S/H:ADC: 1:1
Number of A/D Converters: 2
Architecture: Pipelined
Reference Type: External, Internal
Voltage - Supply, Analog: 2.85V ~ 3.4V
Voltage - Supply, Digital: 1.65V ~ 1.95V
Features: Simultaneous Sampling
Operating Temperature: -40°C ~ 85°C
Package / Case: 56-VFQFN Exposed Pad
Supplier Device Package: 56-HVQFN (8x8)
Mounting Type: Surface Mount
Base Part Number: ADC14
detail: 14 Bit Analog to Digital Converter 2 Input 2 Pipelined 56-HVQFN (8x8)
