دیتاشیت LR645N3-G-P013

LR645

مشخصات دیتاشیت

نام دیتاشیت LR645
حجم فایل 1002.44 کیلوبایت
نوع فایل pdf
تعداد صفحات 16

دانلود دیتاشیت LR645

LR645 Datasheet

مشخصات

  • RoHS: true
  • Category: Power Supply Chip/Linear Voltage Regulators (LDO)
  • Datasheet: Microchip Tech LR645N3-G-P013
  • Output Current: 3mA
  • Output Voltage: 10V
  • Output Polarity: positive
  • Number of Outputs: 1
  • Maximum Input Voltage: 450V
  • Operating Temperature: -55°C~+155°C
  • Quiescent Current (Ground Current): 150uA
  • Power Supply Rejection Ratio (PSRR): 60dB@(120Hz)
  • Package: TO-92
  • Manufacturer: Microchip Tech
  • Series: -
  • Packaging: Tape & Box (TB)
  • Part Status: Active
  • Output Configuration: Positive
  • Output Type: Fixed
  • Number of Regulators: 1
  • Voltage - Input (Max): 450V
  • Voltage - Output (Min/Fixed): 8V
  • Voltage - Output (Max): 12V
  • Voltage Dropout (Max): -
  • Current - Output: 3mA
  • Current - Quiescent (Iq): 150µA
  • PSRR: 60dB (120Hz)
  • Control Features: -
  • Protection Features: -
  • Mounting Type: Through Hole
  • Package / Case: TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
  • Supplier Device Package: TO-92-3
  • Base Part Number: LR645
  • detail: Linear Voltage Regulator IC 1 Output 3mA TO-92-3
