دیتاشیت DS87C530-QNL+
مشخصات دیتاشیت
| نام دیتاشیت | DS83C530,87C530 |
|---|---|
| حجم فایل | 665.504 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 45 |
دانلود دیتاشیت DS83C530,87C530 |
DS83C530,87C530 Datasheet |
|---|
مشخصات
- RoHS: true
- EEPROM: -
- CPU Core: 51Series
- Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
- RAM Size: -
- Watchdog: Yes
- ADC (Bit): -
- DAC (Bit): -
- Datasheet: Analog Devices Inc./Maxim Integrated DS87C530-QNL+
- PWM (Bit): -
- Real-Time Clock: -
- CPU Maximum Speed: 33MHz
- GPIO Ports Number: 32
- Low-Voltage Detect: -
- CCP Capture/Compare: -
- Internal Comparator: -
- Internal Oscillator: Yes
- Peripheral/Function: PWM
- Program Memory Type: FLASH
- Direct Memory Access: -
- Program Storage Size: 16KB
- Universal Serial Bus: -
- communication protocol: -
- Operating Voltage Range: 4.5V~5.5V
- Infrared Data Association: -
- Operating Temperature Range: -40°C~+85°C
- Secure Digital Input and Output: -
- Package: PLCC-52
- Manufacturer: Analog Devices Inc./Maxim Integrated
- Part Status: Active
- Speed: 33MHz
- Data Converters: -
- Operating Temperature: -40°C ~ 85°C (TA)
- Series: 87C
- Supplier Device Package: 52-PLCC (19.13x19.13)
- Package / Case: 52-LCC (J-Lead)
- Packaging: Tube
- Number of I/O: 32
- Core Processor: 8051
- Core Size: 8-Bit
- EEPROM Size: -
- Connectivity: EBI/EMI, SIO, UART/USART
- Mounting Type: Surface Mount
- Oscillator Type: External
- Program Memory Size: 16KB (16K x 8)
- Peripherals: Power-Fail Reset, PWM, WDT
- Base Part Number: DS87C530
- Voltage - Supply (Vcc/Vdd): 4.5V ~ 5.5V
- detail: 8051 87C Microcontroller IC 8-Bit 33MHz 16KB (16K x 8) OTP 52-PLCC (19.13x19.13)
