دیتاشیت MCP1810 Datasheet

MCP1810 Datasheet

مشخصات دیتاشیت

نام دیتاشیت MCP1810 Datasheet
حجم فایل 1887.618 کیلوبایت
نوع فایل pdf
تعداد صفحات 38

MCP1810 Datasheet

دانلود دیتاشیت

سایر مستندات

مستندات دیگری یافت نشد!

مشخصات فنی

  • RoHS: true
  • Category: Power Supply Chip/Linear Voltage Regulators (LDO)
  • Output Current: 100mA
  • Output Voltage: 4.2V~4.2V
  • Dropout Voltage: 0.35V@(100mA)
  • Output Polarity: positive
  • Number of Outputs: 1
  • Maximum Input Voltage: 5.5V
  • Operating Temperature: -40°C~+85°C@(Tj)
  • Quiescent Current (Ground Current): 50nA
  • Power Supply Rejection Ratio (PSRR): 40dB@(100Hz)
  • Package: DFN-8-EP(2x2)
  • Manufacturer: Microchip Tech
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Discontinued at Digi-Key
  • Output Configuration: Positive
  • Output Type: Fixed
  • Number of Regulators: 1
  • Voltage - Input (Max): 5.5V
  • Voltage - Output (Min/Fixed): 4.2V
  • Voltage - Output (Max): -
  • Voltage Dropout (Max): 0.35V @ 100mA
  • Current - Output: 100mA
  • Current - Quiescent (Iq): 50nA
  • Current - Supply (Max): 290µA
  • PSRR: 40dB (100Hz)
  • Control Features: Enable
  • Protection Features: Over Current
  • Mounting Type: Surface Mount
  • Package / Case: 8-VFDFN Exposed Pad
  • Supplier Device Package: 8-VDFN (2x2)
  • Base Part Number: MCP1810
  • detail: Linear Voltage Regulator IC 1 Output 100mA 8-VDFN (2x2)
