TP2104N3-G-P003 Datasheet
Datasheet specifications
| Datasheet's name | TP2104 |
|---|---|
| File size | 366.218 KB |
| File type | |
| Number of pages | 14 |
Download Datasheet TP2104 |
Download Datasheet |
|---|
Other documentations
No other documentation was found!
Technical specifications
- Manufacturer: Microchip Technology
- Series: -
- Packaging: Tape & Reel (TR)
- Part Status: Active
- FET Type: P-Channel
- Technology: MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss): 40V
- Current - Continuous Drain (Id) @ 25°C: 175mA (Tj)
- Drive Voltage (Max Rds On, Min Rds On): 4.5V, 10V
- Rds On (Max) @ Id, Vgs: 6Ohm @ 500mA, 10V
- Vgs(th) (Max) @ Id: 2V @ 1mA
- Vgs (Max): ±20V
- Input Capacitance (Ciss) (Max) @ Vds: 60pF @ 25V
- FET Feature: -
- Power Dissipation (Max): 740mW (Ta)
- Operating Temperature: -55°C ~ 150°C (TJ)
- Mounting Type: Through Hole
- Supplier Device Package: TO-92-3
- Package / Case: TO-226-3, TO-92-3 (TO-226AA)
- detail: P-Channel 40V 175mA (Tj) 740mW (Ta) Through Hole TO-92-3
