دیتاشیت MIC5249-1.8YMM-TR
مشخصات دیتاشیت
| نام دیتاشیت | MIC5249 |
|---|---|
| حجم فایل | 216.394 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 7 |
دانلود دیتاشیت MIC5249 |
MIC5249 Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/Linear Voltage Regulators (LDO)
- Datasheet: Microchip Tech MIC5249-1.8YMM-TR
- Output Current: 300mA
- Output Voltage: 1.8V
- Dropout Voltage: 0.6V@(300mA)
- Output Polarity: positive
- Number of Outputs: 1
- Maximum Input Voltage: 6V
- Operating Temperature: -40°C~+125°C
- Quiescent Current (Ground Current): 200uA
- Power Supply Rejection Ratio (PSRR): 65dB@(120Hz)
- Package: MSOP-8
- Manufacturer: Microchip Tech
- Series: -
- Packaging: Tape & Reel (TR)
- Part Status: Active
- Output Configuration: Positive
- Output Type: Fixed
- Number of Regulators: 1
- Voltage - Input (Max): 6V
- Voltage - Output (Min/Fixed): 1.8V
- Voltage - Output (Max): -
- Voltage Dropout (Max): 0.6V @ 300mA
- Current - Output: 300mA
- Current - Quiescent (Iq): 200µA
- PSRR: 65dB (120Hz)
- Control Features: Enable, Reset
- Protection Features: Over Current, Over Temperature, Under Voltage Lockout (UVLO)
- Mounting Type: Surface Mount
- Package / Case: 8-TSSOP, 8-MSOP (0.118", 3.00mm Width)
- Supplier Device Package: 8-MSOP
- Base Part Number: MIC5249
- detail: Linear Voltage Regulator IC 1 Output 300mA 8-MSOP
