دیتاشیت MAX20059ATCA/VY+
مشخصات دیتاشیت
| نام دیتاشیت | MAX20059 Datasheet |
|---|---|
| حجم فایل | 622.82 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 17 |
دانلود دیتاشیت MAX20059 Datasheet |
MAX20059 Datasheet Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/DC-DC Converters
- Function: Step-down type
- Topology: Step-down
- Datasheet: Analog Devices Inc./Maxim Integrated MAX20059ATCA/VY+
- Output Type: Adjustable
- Input Voltage: 4.5V~72V
- Output Voltage: 0.8V~64.8V
- Number of Outputs: 1
- Switching Frequency: 2.033MHz
- Output Current (Max): -
- Operating Temperature: -40°C~+125°C@(TA)
- Synchronous Rectification: Yes
- Package: DFN-12(3x3)
- Manufacturer: Analog Devices Inc./Maxim Integrated
- Voltage - Input (Max): 72V
- Voltage - Input (Min): 4.5V
- Output Configuration: Positive
- Supplier Device Package: 12-TDFN-EP (3x3)
- Package / Case: 12-WFDFN Exposed Pad
- Frequency - Switching: 200kHz ~ 2.033MHz
- Current - Output: -
- Part Status: Active
- Series: Automotive, AEC-Q100
- Voltage - Output (Max): 64.8V
- Base Part Number: MAX200
- Mounting Type: Surface Mount, Wettable Flank
- Synchronous Rectifier: Yes
- Voltage - Output (Min/Fixed): 0.8V
- detail: Buck Switching Regulator IC Positive Adjustable 0.8V 1 Output 12-WFDFN Exposed Pad
