MAX17634BATP+ دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت MAX17634BATP+	دانلود دیتاشیت

RoHS: true
Category: Power Supply Chip/DC-DC Converters
Function: Step-down type
Topology: Step-down
Datasheet: Analog Devices Inc./Maxim Integrated MAX17634BATP+
Output Type: Fixed
Input Voltage: 4.5V~36V
Output Voltage: 5V
Number of Outputs: 1
Switching Frequency: 2.2MHz
Output Current (Max): 4.25A
Operating Temperature: -40°C~+125°C@(TA)
Synchronous Rectification: Yes
Package: QFN-20-EP(4x4)
Manufacturer: Analog Devices Inc./Maxim Integrated
Voltage - Input (Max): 36V
Voltage - Input (Min): 4.5V
Output Configuration: Positive
Supplier Device Package: 20-TQFN-EP (4x4)
Package / Case: 20-WFQFN Exposed Pad
Frequency - Switching: 400kHz ~ 2.2MHz
Current - Output: 4.25A
Part Status: Active
Series: -
Voltage - Output (Max): -
Base Part Number: MAX176
Mounting Type: Surface Mount
Synchronous Rectifier: Yes
Voltage - Output (Min/Fixed): 5V
detail: Buck Switching Regulator IC Positive Fixed 5V 1 Output 4.25A 20-WFQFN Exposed Pad
