MAXM17623, 24 Datasheet دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت MAXM17623, 24 Datasheet	دانلود دیتاشیت

RoHS: true
Category: Power Supply Chip/DC-DC Converters
Function: Step-down type
Topology: Step-down
Datasheet: Analog Devices Inc./Maxim Integrated MAXM17624AMB+
Output Type: Adjustable
Input Voltage: 2.9V~5.5V
Output Voltage: 1.5V~3.3V
Number of Outputs: 1
Switching Frequency: 4MHz
Output Current (Max): 1A
Operating Temperature: -40°C~+125°C@(TA)
Synchronous Rectification: Yes
Package: EMGA-10(2.1x2.6)
Manufacturer: Analog Devices Inc./Maxim Integrated
Voltage - Input (Max): 5.5V
Voltage - Input (Min): 2.9V
Output Configuration: Positive
Supplier Device Package: 10-eMGA (2.6x2.1)
Package / Case: 10-SMD Module
Frequency - Switching: 4MHz
Current - Output: 1A
Part Status: Active
Series: Himalaya
Voltage - Output (Max): 3.3V
Base Part Number: MAXM176
Mounting Type: Surface Mount
Synchronous Rectifier: Yes
Voltage - Output (Min/Fixed): 1.5V
Packaging: Tray
detail: Buck Switching Regulator IC Positive Adjustable 1.5V 1 Output 1A 10-SMD Module
