MAX14689EWL+T دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | MAX14689EWL+T |
|---|---|
| حجم فایل | 83.031 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 12 |
دانلود دیتاشیت MAX14689EWL+T |
دانلود دیتاشیت |
|---|
سایر مستندات
Part Numbering System 7 pages
MAX14689 12 pages
مشخصات فنی
- RoHS: true
- Category: Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
- Datasheet: Analog Devices Inc./Maxim Integrated MAX14689EWL+T
- Turn-on time: 200us
- Turn-off time: 30us
- Supply Voltage: 1.6V~5.5V
- Switch Circuit: DPDT(DPDT)
- Number of Channels: 1
- On-State Resistance (Max): 450mΩ
- Package: WLP-9(1.26x1.26)
- Manufacturer: Analog Devices Inc./Maxim Integrated
- Multiplexer/Demultiplexer Circuit: 2:2
- Part Status: Active
- Charge Injection: -
- -3db Bandwidth: 110MHz
- Operating Temperature: -40°C ~ 85°C (TA)
- Voltage - Supply, Dual (V±): -
- Supplier Device Package: 9-WLP (1.26x1.26)
- Package / Case: 9-WFBGA, WLBGA
- Switch Time (Ton, Toff) (Max): 200µs, 30µs
- Packaging: Cut Tape (CT)
- Channel-to-Channel Matching (ΔRon): 5mOhm
- Voltage - Supply, Single (V+): 1.6V ~ 5.5V
- Channel Capacitance (CS(off), CD(off)): 25pF
- Mounting Type: Surface Mount
- Series: Beyond-the-Rails™
- Crosstalk: -100dB @ 100kHz
- Number of Circuits: 1
- Current - Leakage (IS(off)) (Max): 100nA
- Base Part Number: MAX14689
- detail: 1 Circuit IC Switch 2:2 450mOhm 9-WLP (1.26x1.26)
