MAX5380LEUK+T دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | MAX5380LEUK+T |
|---|---|
| حجم فایل | 105.999 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 12 |
دانلود دیتاشیت MAX5380LEUK+T |
دانلود دیتاشیت |
|---|
سایر مستندات
Part Numbering System 7 pages
MAX5380-82 12 pages
مشخصات فنی
- RoHS: true
- Category: ADC/DAC/Data Conversion/Digital To Analog Converters (DACs)
- Datasheet: Analog Devices Inc./Maxim Integrated MAX5380LEUK+T
- Interface: I2C
- Resolution: 8Bit
- Output Type: Voltage-缓冲
- Settling Time: 20us
- Supply Voltage: 2.7V~3.6V
- Integral nonlinearity: ±1LSB
- Operating Temperature: -40°C~+85°C
- Package: SOT-23-5
- Manufacturer: Analog Devices Inc./Maxim Integrated
- Mounting Type: Surface Mount
- Number of D/A Converters: 1
- Data Interface: I²C
- Voltage - Supply, Digital: 2.7V ~ 3.6V
- Reference Type: Internal
- Number of Bits: 8
- Part Status: Active
- INL/DNL (LSB): ±1 (Max), ±1 (Max)
- Differential Output: No
- Series: -
- Voltage - Supply, Analog: 2.7V ~ 3.6V
- Base Part Number: MAX5380
- Supplier Device Package: SOT-23-5
- Package / Case: SC-74A, SOT-753
- Packaging: Cut Tape (CT)
- Architecture: Current Steering
- detail: 8 Bit Digital to Analog Converter 1 SOT-23-5
