MAX77816CEWP+T دیتاشیت

مشخصات دیتاشیت

دانلود دیتاشیت MAX77816CEWP+T	دانلود دیتاشیت

RoHS: true
Category: Power Supply Chip/DC-DC Converters
Function: boost converterType;Step-down type
Topology: Step-down;Boost
Datasheet: Analog Devices Inc./Maxim Integrated MAX77816CEWP+T
Output Type: Adjustable
Input Voltage: 2.3V~5.5V
Output Voltage: 2.6V~5.14V
Number of Outputs: 1
Switching Frequency: 2.5MHz
Output Current (Max): 5A
Operating Temperature: -40°C~+85°C
Synchronous Rectification: NO
Package: WLP-20(1.83x2.13)
Manufacturer: Analog Devices Inc./Maxim Integrated
Voltage - Input (Max): 5.5V
Voltage - Input (Min): 2.3V
Output Configuration: Positive
Supplier Device Package: 20-WLP (1.83x2.13)
Package / Case: 20-WFBGA, WLBGA
Frequency - Switching: 2.5MHz
Current - Output: 5A
Part Status: Active
Series: -
Voltage - Output (Max): 5.14V
Base Part Number: MAX778
Mounting Type: Surface Mount
Synchronous Rectifier: No
Voltage - Output (Min/Fixed): 2.6V
detail: Buck, Boost Switching Regulator IC Positive Adjustable 2.6V 1 Output 5A 20-WFBGA, WLBGA
