دیتاشیت MAX20019ATBA/V+
مشخصات دیتاشیت
| نام دیتاشیت | MAX20019, MAX20020 Abridged Datasheet |
|---|---|
| حجم فایل | 915.985 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 18 |
دانلود دیتاشیت MAX20019, MAX20020 Abridged Datasheet |
MAX20019, MAX20020 Abridged Datasheet Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/DC-DC Converters
- Function: Step-down type
- Topology: Step-down
- Datasheet: Analog Devices Inc./Maxim Integrated MAX20019ATBA/V+
- Output Type: Fixed
- Input Voltage: 3.5V~17V
- Number of Outputs: 2
- Switching Frequency: 3.2MHz
- Output Current (Max): 500mA
- Operating Temperature: -40°C~+125°C
- Synchronous Rectification: NO
- Package: DFN-10(2x3)
- Manufacturer: Analog Devices Inc./Maxim Integrated
- Voltage - Input (Max): 17V
- Voltage - Input (Min): 3.5V
- Output Configuration: Positive
- Supplier Device Package: 10-TDFN (2x3)
- Package / Case: 10-WFDFN Exposed Pad
- Frequency - Switching: 3.2MHz
- Current - Output: 500mA, 500mA
- Part Status: Active
- Series: Automotive, AEC-Q100
- Voltage - Output (Max): -
- Base Part Number: MAX200
- Mounting Type: Surface Mount
- Synchronous Rectifier: No
- Voltage - Output (Min/Fixed): 3.3V, 1.8V
- detail: Buck Switching Regulator IC Positive Fixed 3.3V, 1.8V 2 Output 500mA, 500mA 10-WFDFN Exposed Pad
