MCP48FVBxx Datasheet دیتاشیت

MCP48FVBxx Datasheet

مشخصات دیتاشیت

نام دیتاشیت MCP48FVBxx Datasheet
حجم فایل 1010.447 کیلوبایت
نوع فایل pdf
تعداد صفحات 84

دانلود دیتاشیت MCP48FVBxx Datasheet

دانلود دیتاشیت

سایر مستندات

MCP48FxBxx Typical Performance Curves 104 pages

MCP48FVB22-E/UN 84 pages

مشخصات فنی

  • RoHS: true
  • Category: ADC/DAC/Data Conversion/Digital To Analog Converters (DACs)
  • Datasheet: Microchip Tech MCP48FVB11-E/UN
  • Interface: SPI
  • Resolution: 10Bit
  • Output Type: Voltage-缓冲
  • Settling Time: 7.8us
  • Supply Voltage: 2.7V~5.5V
  • Integral nonlinearity: ±0.4LSB;±0.05LSB
  • Operating Temperature: -40°C~+125°C
  • Package: MSOP-10
  • Manufacturer: Microchip Tech
  • Series: -
  • Packaging: Tube
  • Part Status: Active
  • Number of Bits: 10
  • Number of D/A Converters: 1
  • Differential Output: No
  • Data Interface: SPI
  • Reference Type: External, Internal
  • Voltage - Supply, Analog: 2.7V ~ 5.5V
  • Voltage - Supply, Digital: 2.7V ~ 5.5V
  • INL/DNL (LSB): ±0.4, ±0.05
  • Architecture: R-2R
  • Package / Case: 10-TFSOP, 10-MSOP (0.118", 3.00mm Width)
  • Supplier Device Package: 10-MSOP
  • Mounting Type: Surface Mount
  • Base Part Number: MCP48FVB11
  • detail: 10 Bit Digital to Analog Converter 1 10-MSOP
