دیتاشیت PMDPB65UP,115
مشخصات دیتاشیت
| نام دیتاشیت |
PMDPB65UP
|
| حجم فایل |
328.139
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
16
|
مشخصات
-
Manufacturer:
NXP USA Inc.
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Obsolete
-
FET Type:
2 P-Channel (Dual)
-
FET Feature:
Logic Level Gate
-
Drain to Source Voltage (Vdss):
20V
-
Current - Continuous Drain (Id) @ 25°C:
3.5A
-
Rds On (Max) @ Id, Vgs:
70mOhm @ 1A, 4.5V
-
Vgs(th) (Max) @ Id:
1V @ 250µA
-
Gate Charge (Qg) (Max) @ Vgs:
6nC @ 4.5V
-
Input Capacitance (Ciss) (Max) @ Vds:
380pF @ 10V
-
Power - Max:
520mW
-
Operating Temperature:
150°C (TJ)
-
Mounting Type:
Surface Mount
-
Package / Case:
6-UDFN Exposed Pad
-
Supplier Device Package:
DFN2020-6
-
Base Part Number:
PMDPB
-
detail:
Mosfet Array 2 P-Channel (Dual) 20V 3.5A 520mW Surface Mount DFN2020-6
