BFQ67,215 دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت BFQ67	دانلود دیتاشیت

مستندات دیگری یافت نشد!

Manufacturer: NXP USA Inc.
Series: -
Packaging: Cut Tape (CT)
Part Status: Obsolete
Transistor Type: NPN
Voltage - Collector Emitter Breakdown (Max): 10V
Frequency - Transition: 8GHz
Noise Figure (dB Typ @ f): 1.3dB ~ 3dB @ 1GHz ~ 2GHz
Gain: -
Power - Max: 300mW
DC Current Gain (hFE) (Min) @ Ic, Vce: 60 @ 15mA, 5V
Current - Collector (Ic) (Max): 50mA
Operating Temperature: 175°C (TJ)
Mounting Type: Surface Mount
Package / Case: TO-236-3, SC-59, SOT-23-3
Supplier Device Package: TO-236AB (SOT23)
Base Part Number: BFQ67
detail: RF Transistor NPN 10V 50mA 8GHz 300mW Surface Mount TO-236AB (SOT23)
