74HC4052N,652 دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
74HC(T)4052
|
|
حجم فایل
|
237.33
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
29
|
مشخصات فنی
-
Manufacturer:
NXP USA Inc.
-
Series:
-
-
Packaging:
Tube
-
Part Status:
Obsolete
-
Switch Circuit:
SP4T
-
Multiplexer/Demultiplexer Circuit:
4:1
-
Number of Circuits:
2
-
On-State Resistance (Max):
150Ohm
-
Channel-to-Channel Matching (ΔRon):
6Ohm
-
Voltage - Supply, Single (V+):
2V ~ 10V
-
Voltage - Supply, Dual (V±):
±1.5V ~ 5V
-
Switch Time (Ton, Toff) (Max):
58ns, 48ns
-
-3db Bandwidth:
180MHz
-
Charge Injection:
-
-
Channel Capacitance (CS(off), CD(off)):
3.5pF
-
Current - Leakage (IS(off)) (Max):
2µA
-
Crosstalk:
-60dB @ 1MHz
-
Operating Temperature:
-40°C ~ 125°C (TA)
-
Mounting Type:
Through Hole
-
Package / Case:
16-DIP (0.300", 7.62mm)
-
Supplier Device Package:
16-DIP
-
Base Part Number:
74HC40
-
detail:
2 Circuit IC Switch 4:1 150Ohm 16-DIP
