BAP63-05W,115 Datasheet
Datasheet specifications
| Datasheet's name | BAP63-05W |
|---|---|
| File size | 201.057 KB |
| File type | |
| Number of pages | 8 |
Download Datasheet BAP63-05W |
Download Datasheet |
|---|
Other documentations
No other documentation was found!
Technical specifications
- Manufacturer: NXP USA Inc.
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Obsolete
- Diode Type: PIN - 1 Pair Common Cathode
- Voltage - Peak Reverse (Max): 50V
- Current - Max: 100mA
- Capacitance @ Vr, F: 0.35pF @ 20V, 1MHz
- Resistance @ If, F: 1.5Ohm @ 100mA, 100MHz
- Power Dissipation (Max): 240mW
- Operating Temperature: -65°C ~ 150°C (TJ)
- Package / Case: SC-70, SOT-323
- Supplier Device Package: SOT-323
- Base Part Number: BAP63
- detail: RF Diode PIN - 1 Pair Common Cathode 50V 100mA 240mW SOT-323
