74HC21 دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
74HC21
|
|
حجم فایل
|
114.037
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
15
|
مشخصات فنی
-
Manufacturer:
NXP USA Inc.
-
Series:
74HC
-
Packaging:
Tube
-
Part Status:
Obsolete
-
Logic Type:
AND Gate
-
Number of Circuits:
2
-
Number of Inputs:
4
-
Features:
-
-
Voltage - Supply:
2V ~ 6V
-
Current - Quiescent (Max):
2µA
-
Current - Output High, Low:
5.2mA, 5.2mA
-
Logic Level - Low:
0.5V ~ 1.8V
-
Logic Level - High:
1.5V ~ 4.2V
-
Max Propagation Delay @ V, Max CL:
19ns @ 6V, 50pF
-
Operating Temperature:
-40°C ~ 125°C
-
Mounting Type:
Through Hole
-
Supplier Device Package:
14-DIP
-
Package / Case:
14-DIP (0.300", 7.62mm)
-
Base Part Number:
74HC21
-
detail:
AND Gate IC 2 Channel 14-DIP
