PBR951,215 دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت PBR951	دانلود دیتاشیت

مستندات دیگری یافت نشد!

Manufacturer: NXP USA Inc.
Series: -
Packaging: Cut Tape (CT)
Part Status: Obsolete
Transistor Type: NPN
Voltage - Collector Emitter Breakdown (Max): 10V
Frequency - Transition: 8GHz
Noise Figure (dB Typ @ f): 1.3dB ~ 2dB @ 1GHz ~ 2GHz
Gain: -
Power - Max: 365mW
DC Current Gain (hFE) (Min) @ Ic, Vce: 50 @ 5mA, 6V
Current - Collector (Ic) (Max): 100mA
Operating Temperature: 175°C (TJ)
Mounting Type: Surface Mount
Package / Case: TO-236-3, SC-59, SOT-23-3
Supplier Device Package: TO-236AB (SOT23)
Base Part Number: PBR95
detail: RF Transistor NPN 10V 100mA 8GHz 365mW Surface Mount TO-236AB (SOT23)
