TDA1519B دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
TDA1519B
|
|
حجم فایل
|
102.418
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
12
|
مشخصات فنی
-
Manufacturer:
NXP USA Inc.
-
Series:
-
-
Packaging:
Tube
-
Part Status:
Obsolete
-
Type:
Class B
-
Output Type:
1-Channel (Mono) or 2-Channel (Stereo)
-
Max Output Power x Channels @ Load:
12W x 1 @ 8Ohm; 6W x 2 @ 4Ohm
-
Voltage - Supply:
6V ~ 18V
-
Features:
Depop, Mute, Short-Circuit and Thermal Protection, Standby
-
Mounting Type:
Through Hole
-
Operating Temperature:
-
-
Supplier Device Package:
9-SIL MPF
-
Package / Case:
9-SIP Exposed Tab
-
Base Part Number:
TDA151
-
detail:
Amplifier IC 1-Channel (Mono) or 2-Channel (Stereo) Class B 9-SIL MPF
