74F109 دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
74F109
|
|
حجم فایل
|
214.632
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
11
|
مشخصات فنی
-
Manufacturer:
NXP USA Inc.
-
Series:
74F
-
Packaging:
Tube
-
Part Status:
Obsolete
-
Function:
Set(Preset) and Reset
-
Type:
JK Type
-
Output Type:
Differential
-
Number of Elements:
2
-
Number of Bits per Element:
1
-
Clock Frequency:
125MHz
-
Max Propagation Delay @ V, Max CL:
8ns @ 5V, 50pF
-
Trigger Type:
Positive Edge
-
Current - Output High, Low:
1mA, 20mA
-
Voltage - Supply:
4.5V ~ 5.5V
-
Current - Quiescent (Iq):
17mA
-
Operating Temperature:
0°C ~ 70°C (TA)
-
Mounting Type:
Through Hole
-
Supplier Device Package:
16-DIP
-
Package / Case:
16-DIP (0.300", 7.62mm)
-
Base Part Number:
N74F1
-
detail:
Flip Flop 2 Element JK Type 1 Bit Positive Edge 16-DIP (0.300", 7.62mm)
