دیتاشیت PIP202-12M-2,518

PIP202-12M-2

مشخصات دیتاشیت

نام دیتاشیت PIP202-12M-2
حجم فایل 342.034 کیلوبایت
نوع فایل pdf
تعداد صفحات 20

دانلود دیتاشیت PIP202-12M-2

PIP202-12M-2 Datasheet

مشخصات

  • Manufacturer: NXP USA Inc.
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Obsolete
  • Output Configuration: Half Bridge
  • Applications: Synchronous Buck Converters
  • Interface: PWM
  • Load Type: Inductive
  • Technology: Power MOSFET
  • Rds On (Typ): -
  • Current - Output / Channel: 25A
  • Current - Peak Output: 200A
  • Voltage - Supply: 3.3V ~ 12V
  • Voltage - Load: 25V (Max)
  • Operating Temperature: -55°C ~ 150°C (TJ)
  • Features: Bootstrap Circuit
  • Fault Protection: -
  • Mounting Type: Surface Mount
  • Package / Case: 68-VFQFN Exposed Pad
  • Supplier Device Package: 68-HVQFN (10x10)
  • Base Part Number: PIP20
  • detail: Half Bridge Driver Synchronous Buck Converters Power MOSFET 68-HVQFN (10x10)
